ASMedia PCIe Interface Port Packet Switch

PCI Express High-Speed Interface with 16 Lane for 12 Ports

ASMedia PCIe Interface Port Packet Switch supports up to 12 PCIe ports, hot-plug removal, enabling and disabling flow control, and SRIS on both upstream and downstream ports. Drop us a message for more benefits and ordering details of the product.

▌Upstream PCIe interface
  • 1-, 2-, 4-, or 8-lane PCIe® connecting with root port
  • Automatic detection of lane configuration on boot-up
  • Supporting transfer rate of 2.5Gb(250MB/s), 5Gb(500MB/s) per lane
▌Downstream PCIe interface
  • 16 lane PCIe® 3.1 interface supporting up to 12 PCIe® ports
  • Support L0s/L1/L23/L3 power saving states
  • Support L1 substate deep power saving mode
  • Support wake up function in S3/S4
  • Support enabling or disabling flow control on the individual ports
  • Support LTR
  • Support AER
  • Support SRIS on both upstream and downstream ports.
  • Max payload size = 512Byte
  • Support hot-plug surprise removal
▌Packaging
  • LFBGA 21x21, 492L
