ASMedia PCIe Gen2 Packet Switch
High-Performance PCIe Gen2 Packet Switch by ASMedia Technology
ASMedia PCIe Gen2 Packet Switch features 12 lanes for up to 6 downstream ports. It allows high-speed I/O systems for server, storage, communication platforms, and more. Message us through email for any inquiry.
▌Upstream PCIe Interface
- 1-, 2- lane PCIe® connecting with root port
- Automatic detection of lane configuration on boot-up
- Transfer rate of 2.5Gb (250MB/s), 5Gb (500MB/s) per lane
▌Downstream PCIe Interface
- 8 lane PCIe® 2.0 interface supporting up to 6 PCIe® ports
- Support L0s/L1/L23/L3 power saving states
- Support L1 substate deep power saving mode
- Support wake up function in S3/S4
- Support port disabled by individual control
- Support LTR
- Support AER
- Support SRIS on both upstream and downstream ports.
- Max payload size = 512Byte
- Support hot-plug surprise removal
▌Packaging
- LFBGA 21x21, 492L
